Siemens 3G-OTH-44244 — Spesifikasi Teknis

Name: Siemens 3G-OTH-44244 SIEMENS Definite Purpose Contactor: 2 Poles, 277V AC, 40 A, Non-Reversing, Std Contactor Frame Size (MPN 42CF15AL). Key specifications — Brand: SIEMENS; Coil Voltage: 240/277V AC; Mounting Style: Surface; Terminal Connection Type: Quick Disconnect and Screw/Box Lug; Maximum Voltage Rating: 600V AC; Series: 42 Series; Phase: Single; Main Pole Contact Form: 2NO.
Brand: Siemens

The SIEMENS 42 Series Non-Reversing Definite Purpose Contactor is a single-phase, 2-pole device with a 2NO main pole contact form. It features a 240/277V AC coil voltage and a maximum voltage rating of 600V AC. This surface-mount contactor offers quick disconnect and screw/box lug terminal connections.

Lihat Produk & Minta Penawaran

Spesifikasi Teknis

Parameter	Nilai
AC	277V
Type	40 A, Non-Reversing, Std Contactor Frame Size
Brand	SIEMENS
Phase	Single
Series	42 Series
Coil Voltage	240/277V AC
Mounting Style	Surface
Main Pole Contact Form	2NO
Maximum Voltage Rating	600V AC
Manufacturer Part Number	42CF15AL
Terminal Connection Type	Quick Disconnect and Screw/Box Lug
