AEROQUIP CRIMP DIE

Aeroquip, a brand under the Eaton Corporation, is a globally recognized manufacturer of fluid conveyance and connection systems, including hydraulic and industrial hose assemblies, fittings, and crimping equipment. The Aeroquip Crimp Die product line comprises precision-engineered die cages and die sets designed for use with Aeroquip crimping machines to form permanent, leak-free connections on hydraulic hoses. These dies are critical components in the assembly of hose ends, ensuring consistent crimp diameter and force distribution across various hose constructions. The product range includes die cages with maximum crimp diameters from 90 mm to 420 mm, accommodating hose types such as 1-wire braid, 2-wire braid, and spiral hose (4S). Each die cage is finished in black and is compatible with specific Aeroquip crimp machine models, such as the FT1380 and FT1381 series. The dies are constructed from hardened steel to withstand repeated use and maintain dimensional accuracy over time. Key specifications include the maximum crimp diameter, hose type compatibility, and manufacturer part numbers (e.g., FT1380-275-M090, FT1380-200-M150). 3G Electric supplies a comprehensive selection of Aeroquip Crimp Die die cages and die sets, supporting maintenance and production operations in industries such as oil and gas, mining, construction, and manufacturing. The inventory includes multiple SKUs covering a range of sizes and hose configurations, enabling engineers and procurement specialists to source the exact die required for their crimping applications. 3G Electric provides logistics support for global shipping, ensuring that these precision components reach facilities worldwide. The product listings include detailed specifications, allowing technical buyers to compare dimensions, hose compatibility, and machine compatibility before purchase. By offering a broad assortment of Aeroquip Crimp Die products, 3G Electric facilitates the maintenance of hydraulic systems and the assembly of custom hose assemblies, reducing downtime and ensuring reliable fluid power connections.

Asli

Suku Cadang OEM

Ahli

Dukungan Teknis

1 Hari

Respons Penawaran

Seluruh Dunia

Asal

Minta Penawaran Penjualan WhatsApp Penjualan Telegram

Pengiriman ke Seluruh Dunia

Pengiriman udara & laut

Lembar Data Atas Permintaan

Spesifikasi teknis & gambar

Respons Penawaran 1 Hari

Tim berbasis di Singapore

MerekAEROQUIP CRIMP DIE

KategoriAeroquip Dies & Die Sets

MasukTersedia

← Sebelumnya1 2 Berikutnya →

Tentang AEROQUIP CRIMP DIE

Aplikasi Umum

Hydraulic hose assembly in oil and gas extraction — Aeroquip Crimp Die die cages (e.g., FT1380-200-M150) for 2-wire braid hoses.
Mining equipment maintenance — Die cages (e.g., FT1380-200-M320) for spiral hose 4S on high-pressure hydraulic systems.
Construction machinery repair — Aeroquip Crimp Die die cages (e.g., FT1380-275-M090) for 1-wire braid hoses in compact equipment.
Manufacturing plant hydraulic systems — Die cages (e.g., FT1381-200-M280) for large-diameter spiral hoses in presses.
Agricultural machinery service — Aeroquip Crimp Die die cages (e.g., FT1380-200-M180) for 1-wire and 2-wire braid hoses on tractors.
Marine hydraulic system assembly — Die cages (e.g., FT1380-200-M370) for 2-wire braid hoses in shipboard equipment.

Pertanyaan yang Sering Diajukan

Pertanyaan umum tentang AEROQUIP CRIMP DIE dari 3G Electric.

What hose types are compatible with Aeroquip Crimp Die die cages?

Aeroquip Crimp Die die cages are designed to accommodate specific hose constructions. Based on the product range, die cages are available for 1-wire braid, 2-wire braid, and spiral hose (4S) types. Each die cage is labeled with its compatible hose type, such as '1WIRE BRAID' or '2 Wire Braid/Spiral Hose 4S'. It is important to select a die cage that matches the hose construction to ensure proper crimp force and connection integrity. Refer to the manufacturer part number and specifications for exact compatibility.

What is the maximum crimp diameter range for Aeroquip Crimp Die die cages?

The Aeroquip Crimp Die die cages offered by 3G Electric have maximum crimp diameters ranging from 90 mm to 420 mm. Specific models include 90 mm (FT1380-275-M090), 150 mm (FT1380-200-M150), 180 mm (FT1380-200-M180), 210 mm (FT1380-200-M210), 280 mm (FT1381-200-M280), 320 mm (FT1380-200-M320), 370 mm (FT1380-200-M370), and 420 mm (FT1380-200-M420). This range covers small to large hose assemblies for various industrial applications.

Which Aeroquip crimp machines are compatible with these die cages?

The die cages are designed for use with Aeroquip crimp machines, specifically the FT1380 and FT1381 series. For example, models with part numbers starting with FT1380-200- are compatible with FT1380 machines, while the FT1381-200-M280 is for FT1381 machines. The manufacturer part number indicates the machine compatibility. Always verify the machine model before purchasing to ensure proper fit and function.

Are Aeroquip Crimp Die die cages finished with any coating?

Yes, the Aeroquip Crimp Die die cages are finished in black. This finish is likely a corrosion-resistant coating, such as black oxide or paint, to protect the steel from rust and wear during use. The black finish also reduces glare and provides a durable surface for repeated crimping operations.

Can I use a die cage rated for 2-wire braid on 1-wire braid hose?

It is not recommended to use a die cage rated for a different hose construction than specified. Die cages are designed with specific crimp force and diameter profiles for each hose type. Using a die cage intended for 2-wire braid on 1-wire braid hose may result in improper crimp diameter, leading to leaks or hose failure. Always select a die cage that matches the hose construction listed in the specifications.

Does 3G Electric supply AEROQUIP CRIMP DIE products?

Yes — 3G Electric (S) Pte. Ltd. supplies AEROQUIP CRIMP DIE products. We stock the AEROQUIP CRIMP DIE catalog and supply genuine factory-original products with full manufacturer warranty and technical support.
