FINECABLES M12 to RJ45 cordsets, such as the ASI-M12-RJ45-11103 (3 m) and ASI-M12-RJ45-11101 (1 m), are rated IP68 when mated. This rating indicates protection against dust ingress and continuous immersion in water beyond 1 meter depth, as defined by IEC 60529. The IP68 rating applies to the connector interface when properly coupled; the cable jacket is PUR, which resists abrasion and many industrial fluids. For applications requiring a lower but still robust seal, FINECABLES panel-mount RJ45 connectors and adapters are rated IP67, suitable for temporary submersion up to 1 meter.

FINECABLES M12 connectors in the cordsets listed (e.g., ASI-M12-RJ45-11103) use D-coding. D-coding is standardized per IEC 61076-2-101 for 4-pin M12 connectors carrying 100BASE-TX Ethernet signals. It ensures correct pin assignment and prevents mismating with A-coded (sensor/actuator) or B-coded (Profibus) connectors. The D-coded interface supports Cat5e performance up to 100 MHz, suitable for 100 Mbps Ethernet. For higher data rates, FINECABLES also offers components compatible with X-coding or other profiles, though the listed stock focuses on D-coded variants.

Yes, FINECABLES offers right-angle panel feed-through adapters. The ASITPA-4512FD-RA is an M12 female to RJ45 right-angle adapter with 4 pins, and the ASITPA-4512FX-RA is an 8-pin variant. Both are constructed from nickel-plated brass with an IP67 rating. The right-angle design allows for space-constrained installations where a straight adapter would protrude too far from the panel. These adapters are suitable for routing Ethernet signals through enclosure walls while maintaining environmental sealing.

FINECABLES device-side RJ45 connectors (e.g., ASICPICRJ45S) use a phosphor bronze housing, which provides good electrical conductivity and corrosion resistance. Panel feed-through adapters (e.g., ASITPA-4512FD-S) are made from nickel-plated brass, offering mechanical strength and environmental sealing. Protection caps (e.g., ASICPICPC) are molded from black polyamide reinforced with glass fiber, providing impact resistance and UV stability. These material choices are typical for industrial connectors requiring durability in wet or chemically exposed environments.

The FINECABLES cordsets listed (e.g., ASI-M12-RJ45-11103) are specified as Cat5e, supporting frequencies up to 100 MHz and data rates up to 1 Gbps over short distances. For Cat6 performance (250 MHz), FINECABLES offers other product variants not shown in this stock list. The brand's panel-mount RJ45 connector (ASICPICRJ45S) is rated for Cat5e/Cat6, indicating it can be used in Cat6 installations when paired with appropriate cabling. Always verify the specific part number's performance category against your network requirements.

While the provided specifications do not list an explicit temperature range, FINECABLES cordsets with PUR jackets typically operate between -40°C and +80°C, based on common industrial cable standards. The PUR material maintains flexibility at low temperatures and resists oil and abrasion at higher temperatures. For precise limits, refer to the manufacturer's datasheet for the specific part number. The IP68 rating ensures the connector remains sealed across this range when properly mated.
