PASLODE

PASLODE cordless nailers use a proprietary fuel cell, such as the model 816008 (also referenced as 48PD34 or 902600). This fuel cell is a pressurized cartridge that provides the combustion force to drive nails without the need for an air compressor. It is designed for use with PASLODE cordless framing nailers and is classified as an air tool replacement part. The fuel cell is typically paired with a rechargeable battery (e.g., 7.4V DC, 1.2 Ah Li-Ion) to power the tool's electronic ignition and fan system.

Sequential operation requires the user to depress the safety tip against the work surface and then pull the trigger for each individual nail, offering precise placement and reduced risk of accidental discharge. Bump-fire operation allows the user to hold the trigger and bump the tool against the work surface to drive nails rapidly, increasing speed for applications like framing or sheathing. PASLODE offers both modes across its pneumatic and cordless nailer lines, with models like the 500855 (metal connector nailer) featuring sequential mode.

PASLODE air-powered staplers are designed for specific staple dimensions. For example, the model 515700 framing stapler accepts 16-gauge staples with a 1/2-inch crown width and lengths from 3/4 inch to 2 inches. The model 502575 cap stapler uses 18-gauge staples with a 3/8-inch crown width and lengths from 3/4 inch to 1 1/2 inches. Always consult the tool's specifications to ensure correct staple gauge, crown width, and length for optimal performance and to avoid jamming.

PASLODE pneumatic nailers, such as the 500855 metal connector nailer and 515900 siding nailer, operate with compressed air at 1/4 in NPT (National Pipe Thread) fittings. They require a clean, dry air supply at the pressure range specified by the tool (typically 70-120 psi). While they can be used with most standard air compressors, the compressor must provide sufficient airflow (CFM) to match the tool's consumption rate, especially during continuous use. Using an undersized compressor may result in inconsistent fastening.

PASLODE cordless nailers use a 7.4V DC lithium-ion (Li-Ion) battery, such as the model 902654. This battery powers the tool's electronic systems, including the fan that exhausts combustion gases and the spark ignition. The battery is typically rated at 1.2 Ah for models like the 906200 metal connector nailer. It is not oil-resistant and should be stored in a dry environment. The battery is rechargeable and designed for multiple cycles, but replacement is necessary when capacity degrades.

PASLODE nail strips are available in adhesive collation and paper collation. Adhesive collation uses a glue-like substance to hold nails together, which breaks apart upon firing, leaving no debris. Paper collation uses paper tape that disintegrates during use. The choice depends on the application: adhesive collation is common for metal connector nailers (e.g., model 500855) to reduce jamming, while paper collation is used in some siding nailers (e.g., model 515900). Both types are designed for strip collation in specific magazine angles (e.g., 30° or straight).
