Crydom 3G-OTH-37791 — Spesifikasi Teknis

Name: Crydom 3G-OTH-37791 CRYDOM Solid State Relay: Surface Mounted, 12 A Max Output Current, MOSFET, DC Output (MPN D1D12). Key specifications — Brand: CRYDOM; Current Type: DC; Electrical Connection: Screw Clamp; Finger Safe: No; Input Current: 15 mA; Maximum Output Current without Heat Sink: 9 A; Mounting Style: Panel; Output Voltage: 1 to 72V DC.
Brand: Crydom

The CRYDOM D1D12 is a panel-mounted solid-state relay with a DC output voltage range of 1 to 72V DC. It features a Form A switch configuration, a maximum output current of 9 A without a heat sink, and an input current of 15 mA. The relay uses a screw clamp electrical connection and is not finger-safe.

Lihat Produk & Minta Penawaran

Spesifikasi Teknis

Parameter	Nilai
Brand	CRYDOM
Finger Safe	No
Current Type	DC
Input Current	15 mA
Mounting Style	Panel
Output Voltage	1 to 72V DC
Switch Configuration	Form A
Voltage/Current Type	DC Output
Electrical Connection	Screw Clamp
Manufacturer Part Number	D1D12
Maximum Output Current Without Heat Sink	9 A
