Crydom 3G-OTH-39096 — Spesifikasi Teknis

Name: Crydom 3G-OTH-39096 CRYDOM Solid State Relay: Surface Mounted, 5 A Max Output Current, Triac, AC Output (MPN CL240A05R). Key specifications — Brand: CRYDOM; Current Type: AC; Electrical Connection: Screw Clamp; Finger Safe: No; Maximum Output Current without Heat Sink: 2.9 A; Mounting Style: Panel; Output Voltage: 24 to 280V AC; Switch Configuration: Form A.
Brand: Crydom

The CRYDOM Solid State Relay is a panel-mounted, AC-output relay with a Form A (SPST-NO) switch configuration. It accepts an output voltage of 24 to 280V AC and has a maximum output current without heat sink of 2.9 A. The relay features a screw-clamp electrical connection and is not finger-safe.

Lihat Produk & Minta Penawaran

Spesifikasi Teknis

Parameter	Nilai
Brand	CRYDOM
Finger Safe	No
Current Type	AC
Mounting Style	Panel
Output Voltage	24 to 280V AC
Switch Configuration	Form A
Voltage/Current Type	AC Output
Electrical Connection	Screw Clamp
Manufacturer Part Number	CL240A05R
Maximum Output Current Without Heat Sink	2.9 A
