Crydom 3G-OTH-38308 — Spesifikasi Teknis

Name: Crydom 3G-OTH-38308 CRYDOM Solid State Relay: Surface Mounted, 50 A Max Output Current, SCR, AC Output (MPN D53TP50C). Key specifications — Brand: CRYDOM; Current Type: DC; Electrical Connection: Saddle Clamp; Screw; Finger Safe: Yes; Input Current: 35 mA; Maximum Output Current without Heat Sink: Not Recommended; Mounting Style: Panel.
Brand: Crydom

The CRYDOM D53TP50C is a panel-mounted solid-state relay with a surface-mounted design, featuring a Form A (SPST-NO) switch configuration and an SCR output for AC loads. It accepts a DC input current of 35 mA and switches an output voltage of 48 to 530V AC. The relay includes finger-safe saddle-clamp electrical connections and is not recommended for use without a heat sink.

Lihat Produk & Minta Penawaran

Spesifikasi Teknis

Parameter	Nilai
Brand	CRYDOM
Finger Safe	Yes
Current Type	DC
Input Current	35 mA
Mounting Style	Panel
Output Voltage	48 to 530V AC
Switch Configuration	Form A
Voltage/Current Type	AC Output
Electrical Connection	Saddle Clamp
Manufacturer Part Number	D53TP50C
Maximum Output Current Without Heat Sink	Not Recommended
